SAME Explorer3 85


SAME Explorer3 85 tractor photo
2004 - 2012
Model year
Explorer3 Series
Utility tractor
Series map:
Explorer3 75
Explorer3 85
Explorer3 95
55.9kw
63.4kw
71.6kw
Production
ManufacturerSAME
Utility tractor
SAME Explorer3 85 Engine
SAME 4.0L 4-cyl diesel
Fuel tank42.3 gal
160.1 L
Engine details ...
SAME Explorer3 85 Transmissions
15-speed partially synchronized
45-speed three-speed power shift
Transmission details ...
SAME Explorer3 85 Power
Engine (gross)85 hp
63.4 kW
Engine (net)81 hp
60.4 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Two-post ROPS. Available cab with air-conditioning.
Photos
No photos of the SAME Explorer3 85 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow14.3 gpm
54.1 lpm
Tractor hitch
Rear lift10582 lbs
4799 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Dimensions & Tires
Wheelbase92.9 inches
235 cm
Weight8047 to 8378 pounds
Front tire14.9R24
4WD Rear tire16.9R34
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
Explorer3 85 references literature
Explorer 75-85-95 published in 2003, by SAME
