CaseIH Steiger 715 Quadtrac


CaseIH Steiger 715 Quadtrac tractor photo
2024 -
Steiger Quadtrac Series
Articulated Crawler tractor
Series map:
Steiger 645 Quadtrac
Steiger 715 Quadtrac
636.2hp
705.2hp
Production
ManufacturerCaseIH (a part of CNH)
Articulated Crawler tractor
CaseIH Steiger 715 Quadtrac Engine
FPT 15.9L 6-cyl diesel
Fuel tank520 gal
1968.2 L
Exhaust fluid (DEF)85 gal
321.7 L
Engine details ...
CaseIH Steiger 715 Quadtrac Power
Engine (gross)705.2 hp
525.9 kW
Engine (max)767.3 hp
572.2 kW
PTO (claimed)529.6 hp
394.9 kW
Mechanical
Drivearticulated crawler
Final drivesplanetary
Articulated power steering
Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 715 Quadtrac are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center
Valves4 to 8
Pump flow57 gpm
215.7 lpm
 113 gpmOptOptional
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)22250 lbs
10092 kg
DrawbarCat 5
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Wheelbase154 inches
391 cm
Weight61200 lbs
27760 kg
Tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
 330 OptOptional
Batteries3
Battery CCA950
Battery volts12
References
Steiger 715 Quadtrac references literature
TAFS Connect Steiger published in 2024, by New Holland
