CaseIH Magnum 380 Rowtrac


CaseIH Magnum 380 Rowtrac tractor photo
2019 -
Magnum Series
Half-track Crawler tractor
Series map:
Magnum 340 Rowtrac
Magnum 380 Rowtrac
Magnum 400 Rowtrac
335.0hp
373.0hp
391.0hp
Production
ManufacturerCaseIH (a part of CNH)
Half-track Crawler tractor
Original price was $632,596 in 2024
Variants
Magnum 380wheeled
Magnum 380RThalf-track
CaseIH Magnum 380 Rowtrac Engine
FPT 8.7L 6-cyl diesel
Fuel tank163 gal
617.0 L
Exhaust fluid (DEF)26 gal
98.4 L
Engine details ...
CaseIH Magnum 380 Rowtrac Power
Engine (gross)373 hp
278.1 kW
Engine (max)412 hp
307.2 kW
PTO (claimed)315 hp
234.9 kW
Mechanical
Drivehalf-track
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning. AFS
Photos
No photos of the CaseIH Magnum 380 Rowtrac are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensating (PFC)
Pressure3046 psi
210.0 bar
Valves5 or 6
Pump flow44 gpm
166.5 lpm
 59 gpmOptOptional
223.3 lpm
 75 gpmOptOptional
283.9 lpm
Tractor hitch
Rear TypeIV/III
Rear lift19900 lbs
9026 kg
Front lift9426 lbs
4275 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type1000 (1.75)
 540/1000 (1.375)OptOptional
Engine RPM540@1592
 1000@1803
Front PTOindependent
Front PTO Type1000 (1.375)
 540 (1.375)
 1000 (1.75)
Engine RPM1000@1804
Dimensions & Tires
Wheelbase124 inches
314 cm
Weight36000 lbs
16329 kg
Rear tire420/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
Batteries2
Battery volts12
References
Magnum 380 Rowtrac references literature
Magnum AFS Connect published in 2019, by CaseIH
AFS Connect Magnum published in 2021, by CaseIH
