Iseki RTS23
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Iseki RTS23 Engine | |
| Iseki 1.5L 3-cyl diesel | |
| Fuel tank | 7.4 gal 28.0 L |
 Engine details ... | |
| Iseki RTS23 Transmissions | |
| 12-speed gear | |
| 30-speed partial power shift | |
 Transmission details ... |
| Iseki RTS23 Power | |
| Engine | 23.2 hp 17.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Photos | |
| No photos of the Iseki RTS23 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS0 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 523@2500 |
| 819@2500 | |
| 1266@2500 | |
| Dimensions & Tires | |
| Wheelbase | 59.1 inches 150 cm |
| Weight | 2161 to 2513 pounds |
| Front tire | 7-14 |
| Rear tire | 9.5-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| New RTS Series Respa published in 2019, by Iseki | |
| Operator's Manual RTS Series (1825-912-001-8) published in 2019 |
