Claas Arion 530
|
|
| Production | |
| Manufacturer | Claas |
| Row-Crop tractor | |
| Claas Arion 530 Engine | |
| John Deere 4.5L 4-cyl diesel | |
| Fuel tank | 64 gal 242.2 L |
 Engine details ... | |
| Claas Arion 530 Transmissions | |
| 24-speed six-speed power shift | |
| continuously-variable transmission | |
 Transmission details ... |
| Claas Arion 530 Power | |
| Engine (net) | 135 hp 100.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Claas Arion 530 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | load sensing |
| Pressure | 2900 psi 200.0 bar |
| Valves | 2 to 4 |
| Pump flow | 29.1 gpm 110.1 lpm |
| 39.6 gpm ((Optional) 149.9 lpm | |
| Tractor hitch | |
| Rear Type | III |
| Rear lift (at 24"/610mm) | 11244 lbs 5100 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 100.9 inches 256 cm |
| Weight | 13228 lbs 6000 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Arion published in 2023, by Claas |
