Kioti NS5310
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Kioti NS5310 Engine | |
| Daedong 1.8L 3-cyl diesel | |
| Fuel tank | 13.2 gal 50.0 L |
 Engine details ... | |
| Kioti NS5310 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Kioti NS5310 Power | |
| Engine (gross) | 50.3 hp 37.5 kW |
| PTO (claimed) | 41.8 hp 31.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the Kioti NS5310 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 1 or 2 |
| Total flow | 16.5 gpm 62.5 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 2493 lbs 1130 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 2000 |
| Dimensions & Tires | |
| Wheelbase | 75.5 inches 191 cm |
| Weight | 4027 lbs 1826 kg |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Kioti NS5310 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| NS Series published in 2022, by Kitoi |
