New Holland T5.120 Electro Command
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Utility tractor | |
| Original price was $126,099 in 2023 | |
| New Holland T5.120 Electro Command Engine | |
| FPT 3.4L 4-cyl diesel | |
| Fuel tank | 43.6 gal 165.0 L |
| Exhaust fluid (DEF) | 3.2 gal 12.1 L |
 Engine details ... | |
| New Holland T5.120 Electro Command Transmission | |
| 16-speed 8-speed power shift | |
 Transmission details ... |
| New Holland T5.120 Electro Command Power | |
| Engine (gross) | 117 hp 87.2 kW |
| PTO (claimed) | 99 hp 73.8 kW |
| Drawbar (tested) | 76.2 hp 56.8 kW |
| PTO (tested) | 103.5 hp 77.2 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the New Holland T5.120 Electro Command are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 or 3 |
| Mid valves | 2 OptOptional |
| Pump flow | 21.1 gpm 79.9 lpm |
| Steering flow | 11.4 gpm 43.1 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at 24"/610mm) | 8084 lbs 3666 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@1938 |
| 1000@1926 | |
| Dimensions & Tires | |
| Wheelbase | 93.7 inches 237 cm |
| Weight | 10031 lbs 4550 kg |
| Front tire | 14.9R24 |
| Rear tire | 460/85R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Batteries | 12 |
| Battery CCA | 800 |
| Battery volts | 1 |
| References | |
 | |
| T5 Series published in 2017, by New Holland |
