CaseIH Farmall 25A
|
|
| Production | |
| Manufacturer | CaseIH |
| Compact Utility tractor | |
| Variants | |
| Workmaster 25 | similar New Holland model |
| CaseIH Farmall 25A Engine | |
| Mitsubishi 1.3L 3-cyl diesel | |
| Fuel tank | 7.4 gal 28.0 L |
 Engine details ... | |
| CaseIH Farmall 25A Transmissions | |
| 12-speed sync shuttle | |
| hydrostatic | |
 Transmission details ... |
| CaseIH Farmall 25A Power | |
| Engine (gross) | 24.6 hp 18.3 kW |
| PTO (claimed) | 19.2 hp 14.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the CaseIH Farmall 25A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 OptOptional |
| Pump flow | 7.9 gpm 29.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at 24"/610mm) | 1433 lbs 650 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 2000 |
| Dimensions & Tires | |
| Wheelbase | 65.9 inches 167 cm |
| Weight | 2469 lbs 1119 kg |
 Full dimensions and tires ... | |
| CaseIH Farmall 25A attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Farmall Compact 25A Specifications published in 2023, by CaseIH |
