Tractors > Kubota > L4802

Kubota L4802



No photo available
2022 -
L02 Standard Series
Compact Utility tractor
Series map:
L3902
L4802
37.5hp
48.4hp
Production
ManufacturerKubota
Compact Utility tractor
Original price was $23,733 in 2023
Variants
L4802Nnarrow profile
Kubota L4802 Engine
Kubota 2.4L 4-cyl diesel
Fuel tank13.5 gal
51.1 L
Engine details ...
Kubota L4802 Transmissions
8-speed mechanical shuttle
hydrostatic
Transmission details ...
Kubota L4802 Power
Engine (gross)48.4 hp
36.1 kW
Engine (net)46.0 hp
34.3 kW
Gear PTO (claimed)40.5 hp
30.2 kW
Hydro PTO (claimed)39 hp
29.1 kW
Mechanical
Two- or four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post folding ROPS.
Photos
No photos of the Kubota L4802 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow7.8 gpm
29.5 lpm
Steering flow4.7 gpm
17.8 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)2870 lbs
1301 kg
Rear lift (at 24"/610mm)2320 lbs
1052 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic
Rear PTO Type540 (1.375)
Engine RPM540L2475 (gear)
 540@2640 (hydro)
Dimensions & Tires
Wheelbase72.6 inches
184 cm
Weight3296 to 3549 pounds
Front tire7.5L-15
2WD Rear tire14.9-24
Full dimensions and tires ...
Kubota L4802 attachments
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps45
Charging volts12
Battery CCA600
Battery volts12
References
L4802 references literature
L02 Series published in 2022, by Kubota
