Deutz-Fahr Agrotron 215
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Row-Crop tractor | |
| Deutz-Fahr Agrotron 215 Engine | |
| Deutz 7.1L 6-cyl diesel | |
| Fuel tank | 95.1 gal 360.0 L |
| 145.3 galOptOptional 550.0 L | |
 Engine details ... | |
| Deutz-Fahr Agrotron 215 Transmission | |
| 40-speed four-speed power shift | |
 Transmission details ... |
| Deutz-Fahr Agrotron 215 Power | |
| Engine (net) | 197.1 hp 147.0 kW |
| Engine (max) | 226.6 hp 169.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | planetary |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Deutz-Fahr Agrotron 215 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Pressure | 2901 psi 200.0 bar |
| Pump flow | 31.7 gpm 120.0 lpm |
| Tractor hitch | |
| Rear Type | III |
| Rear lift | 23100 lbs 10478 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Front PTO | independent |
| Clutch | electro-hydraulic |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 121.6 inches 308 cm |
| Weight | 18541 lbs 8410 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Agrotron 215-265 published in 2005, by Deutz-Fahr |
