Shibaura SP2100
|
|
| Production | |
| Manufacturer | Shibaura |
| Compact Utility tractor | |
| Shibaura SP2100 Engine | |
| Shibaura 1.0L 3-cyl diesel | |
| Fuel tank | 4.8 gal 18.2 L |
 Engine details ... | |
| Shibaura SP2100 Transmission | |
| 6-speed synchromesh | |
 Transmission details ... |
| Shibaura SP2100 Power | |
| Engine | 20.7 hp 15.4 kW |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical drum brakes | |
| Open operator station. |
| Photos | |
| No photos of the Shibaura SP2100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Control | position control |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 535@2600 |
| 806@2600 | |
| 1053@2600 | |
| Dimensions & Tires | |
| Wheelbase | 52.4 inches 133 cm |
| Weight | 1190 lbs 539 kg |
| Front tire | 4.00-12 |
| Rear tire | 9.5-20 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 65 |
| References | |
 | |
| SP Series published by Shibaura |
