Shibaura SP6040
| | SP Series | | Compact Utility tractor |
|
Series map:
SP6000
SP6040
44.1kw
44.1kw
| Production |
| Manufacturer | Shibaura
|
| Compact Utility tractor |
| Shibaura SP6040 Power |
| Engine (gross) | 59.2 hp
44.1 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Four-post ROPS. Cab optional. |
| Photos |
| No photos of the Shibaura SP6040 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 9.5 gpm
36.0 lpm
|
| Tractor hitch |
| Rear Type | I
|
| | II/I OptOptional
|
| Control | position and draft control
|
| Rear lift | 4575 lbs
2075 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| | independent OptOptional
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| Battery AH | 100
|
| References |
 |
| SP5040 - SP5000 / SP6040 - SP6000 published by Shibaura |
| U.K. Shibaura Catalog published in 1988, by BV Techno-Import |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 21, 2023 |
