Shibaura SP5040
|
|
| Production | |
| Manufacturer | Shibaura |
| Compact Utility tractor | |
| Shibaura SP5040 Engine | |
| Shibaura 2.3L 4-cyl diesel | |
| Fuel tank | 14.5 gal 54.9 L |
 Engine details ... | |
| Shibaura SP5040 Transmission | |
| 12-speed partially synchronized | |
 Transmission details ... |
| Shibaura SP5040 Power | |
| Engine (gross) | 49.3 hp 36.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS. Cab optional. |
| Photos | |
| No photos of the Shibaura SP5040 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 9.5 gpm 36.0 lpm |
| Tractor hitch | |
| Rear Type | I |
| II/I OptOptional | |
| Control | position and draft control |
| Rear lift | 4575 lbs 2075 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| independent OptOptional | |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 77.2 inches 196 cm |
| Weight | 4211 lbs 1910 kg |
| Front tire | 8.3-20 |
| Rear tire | 12.4-32 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| Battery AH | 100 |
| References | |
 | |
| SP5040 - SP5000 / SP6040 - SP6000 published by Shibaura | |
| U.K. Shibaura Catalog published in 1988, by BV Techno-Import |
