Tractors > Massey Ferguson > 6S.145

Massey Ferguson 6S.145



Massey Ferguson 6S.145 tractor photo
2022 -
6S Series
Row-Crop tractor
Series map:
6S.145
6S.155
143.5hp
152.9hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
Massey Ferguson 6S.145 Engine
AGCO Power 4.9L 4-cyl diesel
Fuel tank74 gal
280.1 L
Exhaust fluid (DEF)9.3 gal
35.2 L
Engine details ...
Massey Ferguson 6S.145 Transmissions
24-speed six-speed power shift
continuously-variable transmission
Transmission details ...
Massey Ferguson 6S.145 Power
Engine143.5 hp
107.0 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Massey Ferguson 6S.145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center OptOptional
Pressure2900 psi
200.0 bar
Rear valvesup to 5
Front valvesup to 2
Pump flow26.4 gpm (open)
99.9 lpm
 29.1 gpm (closed)
110.1 lpm
 39.6 gpm (closed optional)
149.9 lpm
 50.2 gpm (closed optional)
190.0 lpm
Tractor hitch
Rear TypeIII
Dyna-6 Rear lift15653 lbs
7100 kg
Dyna-VT Rear lift21164 lbs
9599 kg
Front HitchIII
Front lift7055 lbs
3200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@1980
 540E@1530
 1000@2030
 1000E@1570
Front PTOindependent
Front PTO Type1000
Engine RPM1000@1920
Dimensions & Tires
Wheelbase105.1 inches
266 cm
Weight12787 to 15432 pounds
Front tire420/85R28
Rear tire520/85R38
Full dimensions and tires ...
References
6S.145 references literature
MF 6S - A New Era published in 2021, by Massey Ferguson
MF 6S Series published in 2022, by Massey Ferguson
