Massey Ferguson 6S.135
| | 2022 - |
| 6S Series | | Row-Crop tractor |
|
Series map:
6S.135
134.1hp
| Production |
| Manufacturer | Massey Ferguson (a part of AGCO)
|
| Row-Crop tractor |
| Massey Ferguson 6S.135 Power |
| Engine | 134.1 hp
100.0 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Massey Ferguson 6S.135 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| | closed center OptOptional
|
| Pressure | 2900 psi
200.0 bar
|
| Rear valves | up to 5
|
| Front valves | up to 2
|
| Pump flow | 26.4 gpm (open)
99.9 lpm
|
| | 29.1 gpm (closed)
110.1 lpm
|
| | 39.6 gpm (closed optional)
149.9 lpm
|
| | 50.2 gpm (closed optional)
190.0 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Dyna-6 Rear lift | 15653 lbs
7100 kg
|
| Dyna-VT Rear lift | 21164 lbs
9599 kg
|
| Front Hitch | III
|
| Front lift | 7055 lbs
3200 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@1980
|
| | 540E@1530
|
| | 1000@2030
|
| | 1000E@1570
|
| Front PTO | independent
|
| Front PTO Type | 1000
|
| Engine RPM | 1000@1920
|
| References |
 |
| MF 6S - A New Era published in 2021, by Massey Ferguson |
| MF 6S Series published in 2022, by Massey Ferguson |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on September 25, 2024 |
