TYM T25
|
|
| Production | |
| Manufacturer | TYM |
| Compact Utility tractor | |
| TYM T25 Engine | |
| Yanmar 1.3L 3-cyl diesel | |
 Engine details ... |
| TYM T25 Transmission | |
| hydrostatic | |
 Transmission details ... |
| TYM T25 Power | |
| Engine (gross) | 24.7 hp 18.4 kW |
| PTO (claimed) | 18.3 hp 13.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional. |
| Photos | |
| No photos of the TYM T25 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 6.6 gal 25.0 L |
| Hydraulic system | 5.8 gal 22.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 5.8 gal 22.0 L |
| Rear valves | 1 OptOptional |
| Pump flow | 4.18 gpm 15.8 lpm |
| Total flow | 6.95 gpm 26.3 lpm |
| Steering flow | 2.77 gpm 10.5 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 1534 lbs 695 kg |
| Rear lift (at 24"/610mm) | 1102 lbs 499 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 61 inches 154 cm |
| Weight | 1881 to 2399 pounds |
 Full dimensions and tires ... | |
| TYM T25 attachments | |
| 60" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 40 |
| Battery volts | 12 |
| References | |
 | |
| T25 Sub-Compact published in 2023, by TYM |
