Hurlimann H-306 XE
|
|
Note: the Hurlimann model H-306 XE is the same as the SAME Argon 60. The following data is from the Argon 60 listing. |
| Production | |
| Manufacturer | Hurlimann (a part of SAME) |
| Utility tractor | |
| Hurlimann H-306 XE Engine | |
| SAME 3.0L 3-cyl diesel | |
| Fuel tank | 15.3 gal 57.9 L |
 Engine details ... | |
| Hurlimann H-306 XE Transmissions | |
| 8-speed mechanical shuttle | |
| 12-speed creeper | |
| 16-speed | |
| 24-speed creeper | |
 Transmission details ... |
| Hurlimann H-306 XE Power | |
| Engine | 59 hp 44.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | planetary |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Four-post ROPS. | |
| Photos | |
| No photos of the Hurlimann H-306 XE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 2 or 3 |
| Pump flow | 8.7 gpm 32.9 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 6526 lbs 2960 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E |
| 540/1000 | |
| 540/540E | |
| 1000 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 82.9 inches 210 cm |
| 4WD Wheelbase | 80.9 inches 205 cm |
| Weight | 4542 to 5071 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 420/70R28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| XE published in 1993, by Hurlimann |
