John Deere 6R 145


No photo available
2022 -
6R Series
Utility tractor
Series map:
6R 145
6R 155
144.8hp
152.9hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6R 145 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 6R 145 Transmissions
continuously-variable transmission
24-speed 4-speed power shift
24-speed 8-speed power shift
Transmission details ...
John Deere 6R 145 Power
Engine (gross)144.8 hp
108.0 kW
Engine (max)156.9 hp
117.0 kW
PTO (claimed)113 hp
84.3 kW
Mechanical
Four-wheel drive
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 6R 145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center PFC
Pump flow30 gpm
113.6 lpm
 41 gpmOptOptional
155.2 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift9193 lbs
4169 kg
Front HitchIIIN
Front lift7275 lbs
3299 kg
Dimensions & Tires
Wheelbase108.8 inches
276 cm
Weight15212 lbs
6900 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
6R 145 references literature
6R Utility Tractors published in 2021, by John Deere
