John Deere 6R 120


No photo available
2022 -
6R Series
Utility tractor
Series map:
6R 110
6R 120
6R 130
108.6hp
118.0hp
128.7hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
John Deere 6R 120 Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 6R 120 Transmissions
continuously-variable transmission
24-speed partial power shift
Transmission details ...
John Deere 6R 120 Power
Engine (gross)118 hp
88.0 kW
Engine (max)130.1 hp
97.0 kW
PTO (claimed)91 hp
67.9 kW
Mechanical
Four-wheel drive
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 6R 120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center PFC
Pump flow30 gpm
113.6 lpm
Tractor hitch
Rear TypeIIIN/II
Rear lift7937 lbs
3600 kg
 9039 lbsOptOptional
4100 kg
Front HitchIIIN
Front lift7275 lbs
3299 kg
Dimensions & Tires
Wheelbase102 inches
259 cm
Weight13448 lbs
6100 kg
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
6R 120 references literature
6R Utility Tractors published in 2021, by John Deere
