CaseIH Luxxum 120
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Built in Saint Valentin, Austria | |
| Variants | |
| Farmall 120U | similar CaseIH model |
| CaseIH Luxxum 120 Engine | |
| FPT 3.4L 4-cyl diesel | |
| Fuel tank | 39.6 gal 149.9 L |
| Exhaust fluid (DEF) | 3.7 gal 14.0 L |
 Engine details ... | |
| CaseIH Luxxum 120 Transmission | |
| 32-speed four-speed power shift | |
 Transmission details ... |
| CaseIH Luxxum 120 Power | |
| Engine (gross) | 117 hp 87.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the CaseIH Luxxum 120 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Rear valves | 4 OptOptional |
| Mid valves | 2 OptOptional |
| Pump flow | 21.1 gpm 79.9 lpm |
| 26.4 gpmOptOptional 99.9 lpm | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E/1000/1000E |
| Front PTO | independent |
| Front PTO Type | 540/540E/1000/1000E |
| Dimensions & Tires | |
| Wheelbase | 95.3 inches 242 cm |
| 95.7 inches (suspended axle) 243 cm | |
| Weight | 9678 lbs 4389 kg |
| Front tire | 480/65R24 |
| Rear tire | 540/65R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| References | |
 | |
| Luxxum published in 2016, by CaseIH |
