Massey Ferguson 340
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Utility tractor | |
| Built in Coventry, England | |
| Massey Ferguson 340 Engine | |
| Perkins 2.5L 3-cyl diesel | |
| Fuel tank | 18 gal 68.1 L |
 Engine details ... | |
| Massey Ferguson 340 Transmission | |
| 8-speed gear | |
 Transmission details ... |
| Massey Ferguson 340 Power | |
| Engine | 46 hp 34.3 kW |
| PTO (claimed) | 41 hp 30.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | bevel gear |
| Power steering | |
| Hydraulic drum brakes | |
| Trailer brakes | hydraulic OptOptional |
| Cab standard. | |
| Photos | |
| No photos of the Massey Ferguson 340 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 9.2 gpm (aux pump) 34.8 lpm |
| 4.5 gpm (hitch) 17.0 lpm | |
| Total flow | 13.7 gpm 51.9 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift (at ends) | 4729 lbs*Capacity with links horizontal 2145 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 85.6 inches 217 cm |
| Weight | 5225 lbs 2370 kg |
| Front tire | 10.5/80-18 |
| Rear tire | 14.9/13-24 |
 Full dimensions and tires ... | |
| 340 Serial Number Location | |
 | |
| Serial number plate on the right side of the tractor, near the brake pedals. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Battery CCA | 420 |
| Battery volts | 12 |
| References | |
 | |
| 300 Series Tractors Data Book published in 1992, by Massey Ferguson | |
| M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991 | |
| 340 published in 1988, by Massey Ferguson |
