Rhino 3324 Classic
|
|
| Production | |
| Manufacturer | Rhino |
| Compact Utility tractor | |
| Built in China | |
| Rhino 3324 Engine | |
| 1.7L 2-cyl diesel | |
| Fuel tank | 7 gal 26.5 L |
 Engine details ... | |
| Rhino 3324 Transmission | |
| 8-speed gear | |
 Transmission details ... |
| Rhino 3324 Power | |
| Engine | 32 hp 23.9 kW |
| Mechanical | |
| Drive | 4x2 MFWD 4WD |
| Power steering | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the Rhino 3324 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 2 OptOptional |
| Pump flow | 5.25 gpm 19.9 lpm |
| Steering flow | 3.4 gpm 12.9 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at 24"/610mm) | 1800 lbs 816 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 61.8 inches 156 cm |
| Weight | 3500 lbs 1587 kg |
| Front tire | 7.5x16 |
| Rear tire | 11.2x24 |
 Full dimensions and tires ... | |
| References | |
 | |
| 3320 - 3324 published in 1995, by Rhino |
