Belarus 1005
|
|
| Production | |
| Manufacturer | Belarus |
| Row-Crop tractor | |
| Built in Minsk, Belarus | |
| Belarus 1005 Engine | |
| Belarus 4.7L 4-cyl diesel | |
 Engine details ... |
| Belarus 1005 Power | |
| Engine | 100 hp 74.6 kW |
| PTO (claimed) | 92 hp 68.6 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | spur gear |
| Differential lock | hydraulic |
| Power steering | |
| Mechanical disc brakes | |
| Cab standard. | |
| Photos | |
| No photos of the Belarus 1005 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 34.3 gal 129.8 L |
| Hydraulic system | 5.4 gal 20.4 L |
| Hydraulics | |
| Type | open center |
| Capacity | 5.4 gal 20.4 L |
| Pressure | 2250 psi 155.1 bar |
| Valves | 2 or 3 |
| Pump flow | 11.9 gpm 45.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 4366 lbs 1980 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1632 |
| 1000@1673 | |
| Dimensions & Tires | |
| Wheelbase | 98.4 inches 249 cm |
| Weight | 8874 lbs 4025 kg |
| Front tire | 9.50x20 |
| Rear tire | 16.9x38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 50 |
| Battery volts | 12 |
| References | |
 | |
| 1005 - 1025 published by Belarus |
