CaseIH Farmall 115A
| Production |
| Manufacturer | CaseIH
|
| Utility tractor |
| CaseIH Farmall 115A Power |
| Engine | 120 hp
89.5 kW
|
| PTO (claimed) | 100 hp
74.6 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Photos |
| No photos of the CaseIH Farmall 115A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Rear valves | 2 or 3
|
| Pump flow | 16.9 gpm
64.0 lpm
|
| | 21.6 gpmOptOptional
81.8 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | top-link draft sensing
|
| Rear lift (at ends) | 4409 lbs
1999 kg
|
| Rear lift (at 24"/610mm) | 3200 lbs
1451 kg
|
| | 7716 lbsOptOptional
3499 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| | 540/1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 120
|
| Battery volts | 12
|
| References |
 |
| Farmall Utility 95A/105A/115A Series Tractors published in 2019, by CaseIH |
| Farmall Utility Series Tractors published in 2021, by CaseIH |
