CaseIH Farmall 75A
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Variants | |
| Workmaster 75 | similar New Holland model |
| CaseIH Farmall 75A Engine | |
| FPT 2.9L 3-cyl diesel | |
| Fuel tank | 21.7 gal 82.1 L |
 Engine details ... | |
| CaseIH Farmall 75A Transmissions | |
| 8-speed mechanical shuttle | |
| 12-speed power shuttle | |
| 20-speed creeper | |
 Transmission details ... |
| CaseIH Farmall 75A Power | |
| Engine | 74 hp 55.2 kW |
| PTO (claimed) | 60 hp 44.7 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditoning. | |
| Photos | |
| No photos of the CaseIH Farmall 75A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Rear valves | 2 or 3 |
| Pump flow | 12.6 gpm 47.7 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Rear lift (at ends) | 5952 lbs 2699 kg |
| 6614 lbsOptOptional 3000 kg | |
| Rear lift (at 24"/610mm) | 4299 lbs 1950 kg |
| 4740 lbsOptOptional 2150 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1957 |
| 540E@1592 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 81.2 inches 206 cm |
| 4WD Wheelbase | 81.8 inches 207 cm |
| Weight | 5622 to 6834 pounds |
| Front tire | 9.5L-15 |
| 2WD Rear tire | 16.9R28 |
 Full dimensions and tires ... | |
| CaseIH Farmall 75A attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery volts | 12 |
| References | |
 | |
| Farmall Utility A Series Tractors published in 2018, by CaseIH | |
| Farmall Utility A Series Tractors published in 2019, by CaseIH | |
| Farmall Utility Series Tractors published in 2021, by CaseIH |
