LS XJ2025
|
|
| Production | |
| Manufacturer | LS |
| Compact Utility tractor | |
| Variants | |
| XJ2025 | gear |
| XJ2025H | hydrostatic |
| LS XJ2025 Engine | |
| Mitsubishi 1.3L 3-cyl diesel | |
| Fuel tank | 6.6 gal 25.0 L |
 Engine details ... | |
| LS XJ2025 Transmissions | |
| 6-speed gear | |
| hydrostatic | |
 Transmission details ... |
| LS XJ2025 Power | |
| Engine (gross) | 24.4 hp 18.2 kW |
| Gear PTO (claimed) | 19.5 hp 14.5 kW |
| Hydro PTO (claimed) | 18.5 hp 13.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
| No photos of the LS XJ2025 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Gear Pump flow | 6.9 gpm 26.1 lpm |
| Hydro Pump flow | 5.9 gpm 22.3 lpm |
| Gear Total flow | 8 gpm 30.3 lpm |
| Hydro Total flow | 8.5 gpm 32.2 lpm |
| Gear Steering flow | 1.1 gpm 4.2 lpm |
| Hydro Steering flow | 2.6 gpm 9.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 1433 lbs 650 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | independent |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 2000 |
| Dimensions & Tires | |
| Wheelbase | 59 inches 149 cm |
| Weight | 1609 to 1785 pounds |
 Full dimensions and tires ... | |
| LS XJ2025 attachments | |
| 60" mid-mount mower deck | |
| snowblower | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Battery volts | 12 |
| References | |
 | |
| XJ Series published by LS |
