Massey Ferguson 8S.285
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Row-Crop tractor | |
| Massey Ferguson 8S.285 Engine | |
| AGCO Power 7.4L 6-cyl diesel | |
| Fuel tank | 132 gal 499.6 L |
| Exhaust fluid (DEF) | 11.4 gal 43.1 L |
 Engine details ... | |
| Massey Ferguson 8S.285 Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Massey Ferguson 8S.285 Power | |
| Engine | 281.6 hp 210.0 kW |
| PTO (claimed) | 245.4 hp 183.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | automatic front and rear |
| Power steering | |
| Trailer brakes | pneumatic |
| hydraulic OptOptional | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 8S.285 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load-sensing |
| Rear valves | 5 OptOptional |
| Pump flow | 54.2 gpm 205.1 lpm |
| Tractor hitch | |
| Rear Type | III |
| Control | position and draft control |
| Rear lift (at ends) | 22046 lbs 10000 kg |
| Front lift | 10582 lbs 4799 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Engine RPM | 540E@1577 |
| 1000@1882 | |
| 1000E@1605 | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Engine RPM | 1000@1920 |
| Dimensions & Tires | |
| Wheelbase | 120.1 inches 305 cm |
| Weight | 19180 to 22046 pounds |
| Front tire | 540/65R30 |
| Rear tire | 650/65R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MF 8S published in 2022, by Massey Ferguson | |
| MF 8S Series published in 2023, by Massey Ferguson |
