Kubota M7970
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Kubota M7970 Engine | |
| Kubota 4.3L 4-cyl diesel | |
| Fuel tank | 26.4 gal 99.9 L |
 Engine details ... | |
| Kubota M7970 Power | |
| Engine | 79.5 hp 59.3 kW |
| PTO (claimed) | 76 hp 56.7 kW |
| Mechanical | |
| Two- or four-wheel drive |
| Photos | |
| No photos of the Kubota M7970 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 11 gpm 41.6 lpm |
| Tractor hitch | |
| Rear Type | JISII/I |
| Rear lift | 5952 lbs 2699 kg |
| 7716 lbsOptOptional 3499 kg | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540/850/ground (1.375) |
| Engine RPM | 540@2035 |
| 850@2391 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 87.6 inches 222 cm |
| 4WD Wheelbase | 89 inches 226 cm |
| Weight | 5952 to 6614 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 13.9-36 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Operator's Manual M70 (636830-9971-8) |
