Valtra N114
| | 2015 - 2020 |
| N Series | | Row-Crop tractor |
|
Series map:
N104
N114
N124
77.0kw
85.0kw
92.0kw
| Production |
| Manufacturer | Valtra (a part of AGCO)
|
| Row-Crop tractor |
| Valtra N114 Engine |
| AGCO Power 4.4L 4-cyl diesel |
| Fuel tank | 62.1 gal
235.0 L
|
| | 83.2 galOptOptional
314.9 L
|
| | 42.3 gal (steel tank)
160.1 L
|
| Exhaust fluid (DEF) | 11.9 gal
45.0 L
|
 Engine details ... |
| Valtra N114 Power |
| Engine | 114 hp
85.0 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Valtra N114 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| | closed center OptOptional
|
| Rear valves | 2 to 5
|
| Pump flow | 19.3 gpm (open)
73.1 lpm
|
| | 23.8 gpm (open option)
90.1 lpm
|
| | 30.4 gpm (closed)
115.1 lpm
|
| | 42.3 gpm (closed option)
160.1 lpm
|
| | 52.8 gpm (closed option)
199.8 lpm
|
| Tractor hitch |
| Rear lift | 14162 lbs
6423 kg
|
| | 17534 lbsOptOptional
7953 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Battery volts | 12
|
| References |
 |
| N Series published in 2019, by Valtra |
