Fendt 939 Vario
| | 2010 - 2022 |
|
| 900 Vario Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Fendt (a part of AGCO)
|
| Type: | Row-Crop tractor
|
| Fendt 939 Vario Power |
| Engine (gross): | 396 hp
295.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | continuously-variable transmission
|
 Transmission details ... |
| Photos |
| No photos of the Fendt 939 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 158.5 gal
599.9 L
|
| Exhaust fluid (DEF): | 9.5 gal
36.0 L
|
| Hydraulic system: | 23 gal
87.1 L
|
| Hydraulics |
| Capacity: | 23 gal
87.1 L
|
| Pressure: | 2900 psi
200.0 bar
|
| Rear valves: | 6*Optional
|
| Front valves: | 2*Optional
|
| Pump flow: | 40.2 gpm
152.2 lpm
|
| | 54.2 gpm
205.1 lpm *Optional
|
| Tractor hitch |
| Rear lift: | 26526 lbs
12032 kg
|
| Front lift: | 12553 lbs
5694 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540E/1000
|
| | 1000/1000E
|
| Front PTO: | independent*Optional
|
| Front RPM: | 1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery volts: | 12
|
