Fendt 939 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Row-Crop tractor | |
| Fendt 939 Vario Engine | |
| Deutz 7.8L 6-cyl diesel | |
 Engine details ... |
| Fendt 939 Vario Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Fendt 939 Vario Power | |
| Engine (gross) | 396 hp 295.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Fendt 939 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 158.5 gal 599.9 L |
| Exhaust fluid (DEF) | 9.5 gal 36.0 L |
| Hydraulic system | 23 gal 87.1 L |
| Hydraulics | |
| Capacity | 23 gal 87.1 L |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 6 OptOptional |
| Front valves | 2 OptOptional |
| Pump flow | 40.2 gpm 152.2 lpm |
| 54.2 gpmOptOptional 205.1 lpm | |
| Tractor hitch | |
| Rear lift | 26526 lbs 12032 kg |
| Front lift | 12553 lbs 5694 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540E/1000 |
| 1000/1000E | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 120.1 inches 305 cm |
| Weight | 24030 lbs 10900 kg |
| Front tire | 600/70R34 |
| Rear tire | 710/75R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| 900 Vario published in 2018, by Fendt |
