Production | |
Manufacturer: | Fendt (a part of AGCO) |
Type: | Row-Crop tractor |
Fendt 930 Vario Power | |
Engine (gross): | 305 hp 227.4 kW |
Fendt 930 Vario Engine | |
Deutz 7.8L 6-cyl diesel | |
Engine details ... |
Mechanical | |
Chassis: | 4x4 MFWD 4WD |
Steering: | power |
Brakes: | hydraulic wet disc |
Cab: | Cab standard with air-conditioning. |
Transmission: | continuously-variable transmission |
Transmission details ... |
Photos | |
No photos of the Fendt 930 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity | |
Fuel: | 158.5 gal 599.9 L |
Exhaust fluid (DEF): | 9.5 gal 36.0 L |
Hydraulic system: | 23 gal 87.1 L |
Hydraulics | |
Capacity: | 23 gal 87.1 L |
Pressure: | 2900 psi 200.0 bar |
Rear valves: | 6*Optional |
Front valves: | 2*Optional |
Pump flow: | 40.2 gpm 152.2 lpm |
54.2 gpm 205.1 lpm *Optional |
Tractor hitch | |
Rear lift: | 26526 lbs 12032 kg |
Front lift: | 12553 lbs 5694 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Rear RPM: | 540E/1000 |
1000/1000E | |
Front PTO: | independent*Optional |
Front RPM: | 1000 |
Dimensions & Tires | |
Wheelbase: | 120.1 inches 305 cm |
Weight: | 23876 lbs 10830 kg |
Front tire: | 600/65R34 |
Rear tire: | 350/85R38 |
Full dimensions and tires ... |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Battery volts: | 12 |
