Fendt 924 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Row-Crop tractor | |
| Fendt 924 Vario Engine | |
| Deutz 7.8L 6-cyl diesel | |
| Fuel tank | 158.5 gal 599.9 L |
| Exhaust fluid (DEF) | 15.9 gal 60.2 L |
 Engine details ... | |
| Fendt 924 Vario Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Fendt 924 Vario Power | |
| Engine (gross) | 249 hp 185.7 kW |
| Engine (net) | 210 hp 156.6 kW |
| Engine (max) | 258 hp 192.4 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Fendt 924 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 4 to 8 |
| Pump flow | 42.3 gpm 160.1 lpm |
| 57.1 gpmOptOptional 216.1 lpm | |
| Tractor hitch | |
| Rear lift | 26526 lbs 12032 kg |
| Front lift | 12476 lbs 5659 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540E/1000 |
| 1000/1000E | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 120.1 inches 305 cm |
| Weight | 23589 lbs 10699 kg |
| Front tire | 540/65R34 |
| Rear tire | 650/65R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 300 *Dual 150A alternators. |
| Battery volts | 12 |
| References | |
 | |
| 900 Vario published in 2012, by Fendt |
