CaseIH JXU 85
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| CaseIH JXU 85 Engine | |
| Iveco 4.5L 4-cyl diesel | |
| Fuel tank | 33.6 gal 127.2 L |
 Engine details ... | |
| CaseIH JXU 85 Transmissions | |
| 12-speed mechanical shuttle | |
| 24-speed two-speed power shift | |
| 12-speed power shuttle | |
 Transmission details ... |
| CaseIH JXU 85 Power | |
| Engine (gross) | 84.5 hp 63.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | Electro-hydraulic rear and limited slip front. Electro-hydraulic front optional. |
| Power steering | |
| Wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Two-post folding ROPS. Cab optional. | |
| Photos | |
| No photos of the CaseIH JXU 85 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Rear valves | 3 OptOptional |
| Mid valves | 2 OptOptional |
| Pump flow | 16.1 gpm 60.9 lpm |
| Steering flow | 9.5 gpm 36.0 lpm |
| Tractor hitch | |
| Rear lift | 8598 lbs 3900 kg |
| 10803 lbsOptOptional 4900 kg | |
| Front lift | 5512 lbs 2500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/540E/1000 |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 92.2 inches 234 cm |
| 4WD Wheelbase | 92.5 inches 234 cm |
| Weight | 8929 lbs 4050 kg |
| Front tire | 9.00-16 |
| 2WD Rear tire | 18.4R30 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| JXU Series published in 2008, by CaseIH | |
| JXU Series published in 2008, by CaseIH | |
| 834 published in 1973, by International Harvester |
