Tractors > John Deere > 1630VU

John Deere 1630VU



John Deere 1630VU tractor photo
1974 - 1979
Orchard/Vineyard tractor
Series map:
1030VU
1630VU
34.0kw
41.0kw
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
Built in Getafe, Spain
John Deere 1630VU Engine
John Deere 2.9L 3-cyl diesel
Engine details ...
John Deere 1630VU Transmission
8-speed
Transmission details ...
John Deere 1630VU Power
Engine55 hp
41.0 kW
Mechanical
Two-wheel drive
Final drivesplanetary
Manual steering
Hydraulic wet disc brakes
Two-post mid-mount ROPS.
Photos
No photos of the John Deere 1630VU are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel11.1 gal
42.0 L
Hydraulic system10.2 gal
38.6 L
Hydraulics
Typeopen center
Capacity10.2 gal
38.6 L
Tractor hitch
Rear TypeI
Controlposition and draft control
Power Take-off (PTO)
Rear PTOindepedent
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase63 inches
160 cm
Front tire5.00x15
Rear tire9.5x24
Full dimensions and tires ...
References
1630VU references literature
Tracteurs "Vergers" et "Vignerons" published in 1976, by John Deere
