Production | |
Manufacturer | John Deere |
Orchard/Vineyard tractor | |
Built in Getafe, Spain |
John Deere 930VU Engine | |
John Deere 2.7L 3-cyl diesel | |
Engine details ... |
John Deere 930VU Power | |
Engine | 40.2 hp 30.0 kW |
Mechanical | |
Two-wheel drive | |
Final drives | planetary |
Manual steering | |
Hydraulic wet disc brakes | |
Two-post mid-mount ROPS. |
Photos | |
No photos of the John Deere 930VU are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity | |
Fuel | 7.9 gal 29.9 L |
Hydraulic system | 10.2 gal 38.6 L |
Hydraulics | |
Type | open center |
Capacity | 10.2 gal 38.6 L |
Tractor hitch | |
Rear Type | I |
Control | position and draft control |
Power Take-off (PTO) | |
Rear PTO | indepedent |
Rear PTO Type | 540 (1.375) |
Dimensions & Tires | |
Wheelbase | 63 inches 160 cm |
Front tire | 4.50x16 |
Rear tire | 9.5x24 |
Full dimensions and tires ... |
References | |
Tracteurs "Vergers" et "Vignerons" published in 1976, by John Deere |
