Tractors > Kubota > M7-133

Kubota M7-133



Kubota M7-133 tractor photo
2020 - 2022
M7-3 Series
Utility tractor
Series map:
M7-133
M7-163
96.9kw
111.9kw
Production
ManufacturerKubota
Utility tractor
Built in Bierne, France
Kubota M7-133 Engine
Kubota 6.1L 4-cyl diesel
Fuel tank87.2 gal
330.1 L
Exhaust fluid (DEF)10 gal
37.9 L
Engine details ...
Kubota M7-133 Transmissions
30-speed six-speed power shift
infinitely-variable transmission
Transmission details ...
Kubota M7-133 Power
Engine (gross)130 hp
96.9 kW
Engine (max)150 hp
111.9 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Kubota M7-133 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed-center load-sensing OptOptional
Valves3 to 6
Pump flow21.1 gpm (open)
79.9 lpm
 29.1 gpm (closed)
110.1 lpm
Tractor hitch
Rear TypeIII
Controllower-link draft sensing
Rear lift (at ends)20723 lbs
9399 kg
Front lift7717 lbs
3500 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540E@1608
 540@2005
 1000E@1600
 1000@1995
Front PTOindependent
Front PTO Type1000
Dimensions & Tires
Wheelbase107.1 inches
272 cm
Weight16204 lbs
7350 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
Kubota M7-133 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps150
Battery CCA1000
Battery volts12
Battery AH170
References
M7-133 references literature
M7003 Series published in 2020, by Kubota
