Fendt 1156 Vario MT
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Agricultural Crawler tractor | |
| Variants | |
| MT856 | similar Challenger model |
| Fendt 1156 Vario MT Engine | |
| MAN 15.3L 6-cyl diesel | |
| Fuel tank | 350 gal 1324.8 L |
| Exhaust fluid (DEF) | 35.7 gal 135.1 L |
 Engine details ... | |
| Fendt 1156 Vario MT Transmission | |
| continuously-variable transmission | |
 Transmission details ... |
| Fendt 1156 Vario MT Power | |
| Engine (gross) | 556.5 hp 415.0 kW |
| Mechanical | |
| Drive | crawler |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Fendt 1156 Vario MT are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center pressure-flow compensated |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 4 to 8 |
| Pump flow | 58.1 gpm 219.9 lpm |
| 116.2 gpmOptOptional 439.8 lpm | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000/1000E |
| Dimensions & Tracks | |
| Wheelbase | 118 inches 299 cm |
| Weight | 42000 lbs 19051 kg |
| Tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 325 |
| Batteries | 3 |
| Battery volts | 12 |
| References | |
 | |
| Fednt 1100 Vario MT Series published in 2020, by Fendt | |
| Fednt 1100 Vario MT published in 2020, by Fendt |
