John Deere 7510 Hi-Crop


John Deere 7510 Hi-Crop tractor photo
1999 - 2002
7010 Series
High-Clearance tractor
Series map:
7410 Hi-Crop
7510 Hi-Crop
120.0hp
135.0hp
Production
ManufacturerJohn Deere
High-Clearance tractor
Built in Waterloo, Iowa, USA
Variants
7510row-crop
7510 Hi-Crophigh clearance
John Deere 7510 Hi-Crop Transmissions
12-speed fully synchronized
16-speed partial power shift
Transmission details ...
John Deere 7510 Hi-Crop Power
Engine135 hp
100.7 kW
PTO (claimed)115 hp
85.8 kW
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
ComfortGard cab standard.
Photos
No photos of the John Deere 7510 Hi-Crop are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel50 gal
189.2 L
2WD Hydraulic system15 gal
56.8 L
4WD Hydraulic system17 gal
64.3 L
 16 gal (2WD creeper)
60.6 L
 18 gal (4WD creeper)
68.1 L
Hydraulics
Typeclosed center pressure flow compensated (PFC)
2WD Capacity15 gal
56.8 L
4WD Capacity17 gal
64.3 L
 16 gal (2WD creeper)
60.6 L
 18 gal (4WD creeper)
68.1 L
Pressure2900 psi
200.0 bar
Valves2 to 4
Pump flow16 gpm
60.6 lpm
 26 gpmOptOptional
98.4 lpm
Tractor hitch
Rear Type2
 3N/2 OptOptional
2WD Rear lift7,400 lbs
3356 kg
4WD Rear lift8,390 lbs
3805 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
7510 Hi-Crop Serial Numbers
Location:Above front axle on the 7510's main frame.
200030001
200150001
200270001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging amps120
Battery CCA925
Battery volts12
Battery Group31
References
7510 Hi-Crop references literature
7000 TEN Series published in 1999, by John Deere
