Fendt Farmer 409 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Row-Crop tractor | |
| Fendt Farmer 409 Vario Engine | |
| Deutz 4.0L 4-cyl diesel | |
 Engine details ... |
| Fendt Farmer 409 Vario Transmission | |
| continuously variable transmission | |
 Transmission details ... |
| Fendt Farmer 409 Vario Power | |
| Engine (gross) | 91.2 hp 68.0 kW |
| Engine (net) | 84.5 hp 63.0 kW |
| Engine (max) | 99.2 hp 74.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Cab standard with heat. Air-conditioning optional. |
| Photos | |
| No photos of the Fendt Farmer 409 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | load sensing |
| Pressure | 2900 psi 200.0 bar |
| Pump flow | 19.8 gpm 74.9 lpm |
| Tractor hitch | |
| Rear lift | 14480 lbs 6568 kg |
| Front lift | 6565 lbs 2977 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/750/1000 |
| Front PTO | independent OptOptional |
| Front PTO Type | 540 |
| 1000 | |
| Dimensions & Tires | |
| Wheelbase | 95.2 inches 241 cm |
| Weight | 11177 lbs 5069 kg |
| Front tire | 440/65R24 |
| Rear tire | 540/65R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 143 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 90 |
| References | |
 | |
| Farmer 400 Vario 409 410 411 412 published in 2006, by Fendt | |
| Farmer 400 Vario 409 410 411 412 published in 2006, by Fendt |
