Fendt 314 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Utility tractor | |
| Fendt 314 Vario Engine | |
| AGCO Power 4.4L 4-cyl diesel | |
| Fuel tank | 55.5 gal 210.1 L |
| Exhaust fluid (DEF) | 6.1 gal 23.1 L |
 Engine details ... | |
| Fendt 314 Vario Transmission | |
| continuously variable transmission | |
 Transmission details ... |
| Fendt 314 Vario Power | |
| Engine (gross) | 130.1 hp 97.0 kW |
| Engine (max) | 150.2 hp 112.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | automatic front and rear differential lock |
| Power steering | |
| Wet disc brakes | |
| Trailer brakes | hydraulic |
| VisioPlus Cab standard with air-conditioning and suspension. Optional pneumatic cab suspension (Profi/Profi+). | |
| Photos | |
| No photos of the Fendt 314 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| closed center OptOptional | |
| Pressure | 2900 psi 200.0 bar |
| Rear valves | 2 to 4 |
| Front valves | 1 OptOptional |
| Pump flow | 22.2 gpm 84.0 lpm |
| 29.1 gpm (variable flow) 110.1 lpm | |
| Tractor hitch | |
| Rear lift | 13140 lbs 5960 kg |
| Front lift | 6900 lbs 3129 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E/1000 |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 95.3 inches 242 cm |
| Weight | 11045 lbs 5010 kg |
| Front tire | 480/65R24 |
| Rear tire | 540/65R38 |
 Full dimensions and tires ... | |
| Fendt 314 Vario attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Fendt 300 Vario published in 2020 |
