Fendt 312 Vario
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Fendt 312 Vario Engine | |
| Deutz 4.0L 4-cyl diesel | |
| Fuel tank | 55.5 gal 210.1 L |
 Engine details ... | |
| Fendt 312 Vario Transmission | |
| continuously variable transmission | |
 Transmission details ... |
| Fendt 312 Vario Power | |
| Engine (net) | 108.6 hp 81.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Cab standard with heat. Air-conditioning optional. |
| Photos | |
| No photos of the Fendt 312 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2900 psi 200.0 bar |
| Valves | 2 to 4 |
| Pump flow | 20.6 gpm 78.0 lpm |
| Tractor hitch | |
| Rear lift | 11865 lbs 5381 kg |
| Front lift | 6607 lbs 2996 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E/1000 |
| Front PTO | independent OptOptional |
| Front PTO Type | 540 |
| 1000 | |
| Dimensions & Tires | |
| Wheelbase | 92.5 inches 234 cm |
| Weight | 9590 lbs 4350 kg |
| Front tire | 480/65R24 |
| Rear tire | 540/65R38 |
 Full dimensions and tires ... | |
| Fendt 312 Vario attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 143 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 90 |
| References | |
 | |
| Fendt 300 Vario published in 2006 |
