Fendt Farmer 309Ci
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Fendt Farmer 309Ci Engine | |
| Deutz 4.0L 4-cyl diesel | |
| Fuel tank | 29.1 gal 110.1 L |
 Engine details ... | |
| Fendt Farmer 309Ci Transmissions | |
| 21-speed synchronized | |
| 21-speed shuttle | |
 Transmission details ... |
| Fendt Farmer 309Ci Power | |
| Engine (net) | 103.3 hp 77.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic disc brakes | |
| Cab standard with heat. Air-conditioning optional. |
| Photos | |
| No photos of the Fendt Farmer 309Ci are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2900 psi 200.0 bar |
| Valves | 2 to 4 |
| Pump flow | 18.5 gpm 70.0 lpm |
| Tractor hitch | |
| Rear Type | III/II |
| Rear lift | 10979 lbs 4980 kg |
| Front lift | 6493 lbs 2945 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/750/1000 |
| Front PTO | independent OptOptional |
| Front PTO Type | 540 |
| 1000 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 94 inches 238 cm |
| 4WD Wheelbase | 89.8 inches 228 cm |
| Weight | 8951 to 9304 pounds |
| Front tire | 440/65R24 |
| Rear tire | 540/65R34 |
 Full dimensions and tires ... | |
| Fendt Farmer 309Ci attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 95 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 90 |
| References | |
 | |
| Farmer 307Ci - 308Ci - 309Ci published in 2005, by Fendt |
