Deutz-Fahr 4050E Keyline
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr 4050E Keyline Engine | |
| SDF 3.0L 3-cyl diesel | |
| Fuel tank | 14.5 gal 54.9 L |
 Engine details ... | |
| Deutz-Fahr 4050E Keyline Transmissions | |
| 8-speed gear | |
| 12-speed creeper | |
| 8-speed partially synchronized | |
 Transmission details ... |
| Deutz-Fahr 4050E Keyline Power | |
| Engine | 49.4 hp 36.8 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical |
| Power steering | |
| Open operator station. Two-post ROPS available. | |
| Photos | |
| No photos of the Deutz-Fahr 4050E Keyline are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 2 to 4 |
| Pump flow | 8.2 gpm 31.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 3527 lbs 1599 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| 540/540E OptOptional | |
| 540/1000 OptOptional | |
| Dimensions & Tires | |
| 2WD Wheelbase | 75.6 inches 192 cm |
| 4WD Wheelbase | 76.8 inches 195 cm |
| Weight | 4630 to 5512 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 4E Keyline Series published in 2019, by Deutz-Fahr |
