Deutz-Fahr 4080.4E
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr 4080.4E Engine | |
| SDF 4.0L 4-cyl diesel | |
| Fuel tank | 18.5 gal 70.0 L |
 Engine details ... | |
| Deutz-Fahr 4080.4E Transmission | |
| 30-speed partially synchronized | |
 Transmission details ... |
| Deutz-Fahr 4080.4E Power | |
| Engine | 78.9 hp 58.8 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical |
| Power steering | |
| Wet disc brakes | |
| Open operator station. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the Deutz-Fahr 4080.4E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Valves | 2 |
| Pump flow | 11.1 gpm 42.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Rear lift | 7717 lbs 3500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/540E |
| Dimensions & Tires | |
| 2WD Wheelbase | 80.4 inches 204 cm |
| 4WD Wheelbase | 77.8 inches 197 cm |
| Weight | 6173 to 7165 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 4050E - 4065E - 4075E - 485E - 4080.4E - 4090.4E - 4100.4E published in 2019, by Deutz-Fahr |
