TYM T264
| | 2019 - |
| Compact Utility tractor |
|
| Production |
| Manufacturer | TYM
|
| Compact Utility tractor |
| TYM T264 Power |
| Engine (gross) | 24.1 hp
18.0 kW
|
| PTO (claimed) | 18.3 hp
13.6 kW
|
| Mechanical |
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. |
| Photos |
| No photos of the TYM T264 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pump flow | 4.4 gpm
16.7 lpm
|
| Total flow | 7.1 gpm
26.9 lpm
|
| Steering flow | 2.7 gpm
10.2 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 1503 lbs
681 kg
|
| Rear lift (at 24"/610mm) | 1102 lbs
499 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | independent
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging amps | 50
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on August 17, 2020 |
