John Deere 6175M



John Deere 6175M tractor photo
2015 - 2025
Model year
6M Series
Utility tractor
Series map:
6155M
6175M
6195M
155.0hp
175.0hp
196.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $159,687 in 2020
John Deere 6175M Engine
John Deere 6.8L 6-cyl diesel
Fuel tank85.9 gal
325.1 L
Exhaust fluid (DEF)5.3 gal
20.1 L
Engine details ...
John Deere 6175M Transmissions
16-speed four-speed power shift
20-speed four-speed power shift
Transmission details ...
John Deere 6175M Power
Engine (gross)175 hp
130.5 kW
Engine (max)194 hp
144.7 kW
PTO (claimed)141 hp
105.1 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning. AutoTrac ((Optional));JDLink ((Optional))
Photos
No photos of the John Deere 6175M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure and flow compensated
Rear valves2 to 4
Front valves0 to 3
Pump flow30 gpm
113.6 lpm
 41 gpmOptOptional
155.2 lpm
Tractor hitch
Rear TypeIIIN/III
Controlelectronic lower link draft sensing
Rear lift17747 lbs
8050 kg
 19952 lbsOptOptional
9050 kg
Front HitchIIIN OptOptional
Front lift9700 lbs
4399 kg
DrawbarCat. 2
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1960
 1000@1960
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@1969
Dimensions & Tires
Wheelbase110.2 inches
279 cm
Weight16534 lbs
7499 kg
Front tire320/85R34/85R28
Rear tire460/85R42
Full dimensions and tires ...
John Deere 6175M attachments
front-end loader
Attachment details ...
6175M Serial Numbers
Location:Serial number plate on the right side of the main tractor frame.
Electrical
Groundnegative
Charging systemalterntor
Charging amps120
 150 OptOptional
 200 OptOptional
Charging volts14
Battery volts12
Battery AH154
 174 OptOptional
