Tractors > John Deere > 6140M

John Deere 6140M



John Deere 6140M tractor photo
2020 -
6M Series
Utility tractor
Series map:
6130M
6140M
6145M
130.0hp
140.0hp
145.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $125,822 in 2020
John Deere 6140M Engine
John Deere 4.5L 4-cyl diesel
Fuel tank51.5 gal
194.9 L
Exhaust fluid (DEF)3.4 gal
12.9 L
Engine details ...
John Deere 6140M Transmissions
16-speed four-speed power shift
24-speed four-speed power shift
infinitely variable transmission (IVT)
Transmission details ...
John Deere 6140M Power
Engine (gross)140 hp
104.4 kW
Engine (max)166 hp
123.8 kW
PTO (claimed)109 hp
81.3 kW
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning. AutoTrac ((Optional));JDLink ((Optional))
Photos
No photos of the John Deere 6140M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center PFC OptOptional
Rear valves2 to 4
Front valves0 to 3
Pump flow21.2 gpm (open)
80.2 lpm
 30 gpm (closed)
113.6 lpm
Tractor hitch
Rear TypeIIIN
Controlelectronic lower link draft sensing
Rear lift11023 lbs
5000 kg
 12556 lbsOptOptional
5695 kg
Front HitchIIIN OptOptional
Front lift9700 lbs
4399 kg
DrawbarCat. 2
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1977
 1000@1972
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@1969
Dimensions & Tires
Wheelbase101.6 inches
258 cm
Weight12786 lbs
5799 kg
Front tire540/65R24
Rear tire600/65R38
Full dimensions and tires ...
John Deere 6140M attachments
front-end loader
Attachment details ...
6140M Serial Numbers
Location:Serial number plate on the right side of the main tractor frame.
Electrical
Groundnegative
Charging systemalterntor
Charging amps120
 150 OptOptional
 200 OptOptional
Charging volts14
Battery volts12
Battery AH154
 174 OptOptional
