John Deere 8R 310


John Deere 8R 310 tractor photo
2019 -
8R Series
Row-Crop tractor
Series map:
8R 280
8R 310
8R 340
280.0hp
310.0hp
340.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Original price was $385,695 in 2020
Variants
8R 310wheeled
8RT 310two-track
8RX 310four-track
John Deere 8R 310 Engine
John Deere 9.0L 6-cyl diesel
Fuel tank192 gal
726.7 L
Exhaust fluid (DEF)9.8 gal
37.1 L
Engine details ...
John Deere 8R 310 Transmissions
16-speed full power shift
23-speed full power shift
infinitely variable transmission
Transmission details ...
John Deere 8R 310 Power
Engine (gross)310 hp
231.2 kW
Engine (max)341 hp
254.3 kW
PTO (claimed)257 hp
191.6 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 8R 310 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center pressure flow compensated
Pressure2958 psi
204.0 bar
Rear valves4 to 6
Pump flow60 gpm
227.1 lpm
 84 gpmOptOptional
317.9 lpm
SCV flow35 gpm (rear)
132.5 lpm
Tractor hitch
Rear TypeIVN/III
Controlelectro-hydraulic draft sensing
Rear lift (at 24"/610mm)20000 lbs
9072 kg
 15200 lbsOptOptional
6894 kg
Front HitchIIIN
Front lift (at ends)11464 lbs
5200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@2003
 1000E@1596
Dimensions & Tires
Wheelbase120.1 inches
305 cm
Weight27800 lbs
12610 kg
Front tire420/85R34
Rear tire480/80R50
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps250
 330 OptOptional
Batteries2
Battery CCA925
Battery volts12
Battery Group31
References
8R 310 references literature
Operator's Manual 8R Tractors (OMRE593195) published in 2021
