John Deere 8R 230


John Deere 8R 230 tractor photo
2019 -
8R Series
Row-Crop tractor
Series map:
8R 230
8R 250
230.0hp
250.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Original price was $283,001 in 2020
John Deere 8R 230 Engine
John Deere 9.0L 6-cyl diesel
Fuel tank192 gal
726.7 L
Exhaust fluid (DEF)9.8 gal
37.1 L
Engine details ...
John Deere 8R 230 Transmissions
16-speed full power shift
23-speed full power shift
infinitely variable transmission
Transmission details ...
John Deere 8R 230 Power
Engine (gross)230 hp
171.5 kW
Engine (max)253 hp
188.7 kW
PTO (claimed)182 hp
135.7 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 8R 230 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center pressure flow compensated
Pressure2958 psi
204.0 bar
Rear valves4 to 6
Pump flow60 gpm
227.1 lpm
 84 gpmOptOptional
317.9 lpm
SCV flow35 gpm (rear)
132.5 lpm
Tractor hitch
Rear TypeIII/IIIN
 IVN/III OptOptional
Controlelectro-hydraulic draft sensing
Rear lift (at 24"/610mm)15200 lbs
6894 kg
 18500 lbs*Optional with 120mm rear axle.
8391 kg
 20000 lbs*Optional with 120mm rear axle.
9072 kg
Front HitchIIIN
Front lift (at ends)11464 lbs
5200 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@2003
 1000E@1596
Dimensions & Tires
Wheelbase121.3 inches
308 cm
 120.1 inches (ILS axle)
305 cm
Weight27800 lbs
12610 kg
Front tire420/90R30
Rear tire480/80R46
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps250
 330 OptOptional
Batteries2
Battery CCA925
Battery volts12
Battery Group31
References
8R 230 references literature
Operator's Manual 8R Tractors (OMRE593195) published in 2021
