Production | |
Manufacturer | Yanmar |
Compact Utility tractor |
Yanmar EF328VJ Engine | |
Yanmar 1.5L 3-cyl diesel | |
Fuel tank | 9.5 gal 36.0 L |
Engine details ... |
Yanmar EF328VJ Transmission | |
20-speed four-speed power shift | |
Transmission details ... |
Yanmar EF328VJ Power | |
Engine | 27.6 hp 20.6 kW |
Mechanical | |
Four-wheel drive |
Photos | |
No photos of the Yanmar EF328VJ are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Tractor hitch | |
Rear Type | JIS1 |
Rear lift | 3307 lbs 1500 kg |
Power Take-off (PTO) | |
Rear PTO | 540 (1.375) |
Engine RPM | 547@2600 |
  | 755@2600 |
  | 955@2600 |
  | 1248@2600 |
  | -600@2600 |
Dimensions & Tires | |
Wheelbase | 64.6 inches 164 cm |
Weight | 3064 to 3483 pounds |
Front tire | 7-16 |
Rear tire | 12.4-24 |
Full dimensions and tires ... |
Electrical | |
Ground | negative |
Battery volts | 12 |
References | |
EF300V Series published in 2005, by Yanmar | |
EF300V Series (0A041-J00501) published in 2009 |
